5836 Nidec | 1/3 hp 1075 RPM 4-Speed 208-230V; 5.6" Blower Motor
5836 Nidec | 1/3 hp 1075 RPM 4-Speed 208-230V; 5.6" Blower Motor
5836 Nidec | 1/3 hp 1075 RPM 4-Speed 208-230V; 5.6" Blower Motor
5836 Nidec | 1/3 hp 1075 RPM 4-Speed 208-230V; 5.6" Blower Motor

Nidec

5836 Nidec | 1/3 hp 1075 RPM 4-Speed 208-230V; 5.6" Blower Motor

(No reviews) Write a Review
$223.10
$198.94
SKU 5836
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 1/3 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 2.3 Amps
Bearings Sleeve Bearings
Speeds 4-Speed
Insulation Class Class B
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1/3 hp 1075 RPM, 4-Speed 208-230V 2.3 amps
  • Shaft 6" x 1/2"
  • Rotation = Reversible
  • 5 5/8" Diameter
  • Motor case length 4.7"
  • Sleeve Bearings
  • 6MFD 370V Capacitor REQUIRED (Our Part #6DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Open Enclosure; Air Over; Class B Insulation; 40C Ambient Temperature; 36" Leads. Application: Furnace blower motor.  Includes 2.25" Dia. hub rings with kit for 2.5" included. Reference: K055KDB9445022B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 1/3 HP
RPM 1075
Type Permanent Split Capacitor
Amperage 2.3 Amps
Bearings Sleeve Bearings
Speeds 4-Speed
Insulation Class Class B
Duty Continuous Duty
!
