FD13BM2PZYR Nidec | 1/3 hp 1800 RPM 56Y Frame TENV 115/230V Nidec Electric Auger Drive Motor

FD13BM2PZYR Nidec | 1/3 hp 1800 RPM 56Y Frame TENV 115/230V Nidec Electric Auger Drive Motor

This Nidec electric auger drive motor is designed for direct drive poultry and swine feeding systems, providing reliable and efficient operation. It serves as a replacement for model S055RED7948034B and Dayton 3K994 motors.

Key Specifications

• Horsepower: 1/3 hp
• RPM: 1800
• Voltage: 115/230V, 60 Hz
• Amperage: 5.3/2.6 amps
• Enclosure: TENV (Totally Enclosed Non-Ventilated)
• Frame / Diameter: 56Y Frame, 1/2" Diameter x 1.75" with flat
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This split phase motor features a round body with a C-face mount for straightforward installation. It includes manual overload protection and Class B insulation, suitable for continuous duty at 40°C ambient temperature. The motor’s design ensures durability and compatibility with standard auger drive applications in agricultural environments.

Warranty

1 Year Manufacturer Warranty
