8330 Nidec | 1/4 hp 1350/1625 RPM 1-Speed 230V; 5.6" Blower Motor

8330 Nidec | 1/4 hp 1350/1625 RPM 1-Speed 230V; 5.6" Blower Motor

This 1/4 horsepower blower motor is designed for HVAC and industrial applications requiring reliable, continuous duty performance. It serves as a suggested aftermarket replacement for Tecumseh models KA55HXKGD8330, TFM1862, 810E186A82, and KA55KGD8330613B.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 1350/1625
• Voltage: 230V
• Amperage: 1.9 amps
• Enclosure: Open Air Over
• Frame / Diameter: 5.6" diameter
• Shaft Dimensions: 0.5" diameter x 2.188" length
• Rotation: CCW shaft end
• Bearings: Sleeve bearings

Product Features & Fitment

This permanent split capacitor motor includes a capacitor and features automatic overload protection for enhanced durability. It is rated for continuous duty with Class B insulation and operates efficiently at ambient temperatures up to 40°C. The motor comes with 40" leads and is compatible with both 50 and 60 Hertz power supplies.

Cross Reference

• Tecumseh KA55HXKGD8330, TFM1862, 810E186A82, KA55KGD8330613B

Warranty

1 Year Manufacturer Warranty
