6129 Nidec | 1/4 hp 1625 RPM 1-Speed 208-230V; 5.6" Condenser Motor

6129 Nidec | 1/4 hp 1625 RPM 1-Speed 208-230V; 5.6" Condenser Motor

This 1/4 horsepower condenser motor by Nidec is designed for heat pump and furnace applications. It serves as a reliable aftermarket replacement for Copeland condenser fan motor model 050-0250-00 and Century/AO Smith OCP0250.

Key Specifications

• Horsepower: 1/4 hp
• RPM: 1625
• Voltage: 208-230V
• Amperage: 1.5 amps
• Enclosure: Open Air Over
• Frame / Diameter: 5.6" diameter, motor case length 4.31"
• Shaft Dimensions: 1/2" x 2.5" shaft, 3" shaft height
• Rotation: CCW shaft end
• Bearings: Sleeve bearings

Product Features & Fitment

This motor features a permanent split capacitor design with automatic overload protection for continuous duty operation. It includes a capacitor and comes with 36" leads for easy wiring. The motor is designed for horizontal mounting only and utilizes a resilient mount to reduce vibration. It is rated for Class B insulation and suitable for ambient temperatures up to 40°C.

Cross Reference

• Century/AO Smith OCP0250

Warranty

1 Year Manufacturer Warranty
