sale
Nidec
3360 Nidec | 1/5 hp, 1040 RPM 3-Speed 277-265V Carrier Blower
(No reviews)
Write a Review
Write a Review
Nidec
3360 Nidec | 1/5 hp, 1040 RPM 3-Speed 277-265V Carrier Blower
$294.40
$263.24
SKU
3360
Availability
Subject to availability
Shipping
Free Shipping
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
Voltage
277/265V
Horsepower
1/5 HP
RPM
1040
Enclosure
TEAO
Type
PSC (Permanent Split Capacitor)
Amperage
1.3 Amps
Bearings
Sleeve Bearings
Speeds
3-Speed
Rotation
Clockwise
- 1/5 hp 1040 RPM 3-Speed 277-265V, 1.3 amps
- Shaft 7.0" x 1/2" x 3.0"
- Rotation CW lead end
- TEAO
- Sleeve Bearings
- Body diameter 5-5/8"
- 39" and 51" leads
- Motor case length 3.812"
- Bracket Mount
- 3.0 MFD capacitor (2-Prong) required (NOT INCLUDED)
- 1 Year Manufacture Warranty.
PSC Motor, Totally Enclosed Air Over Enclosure, Automatic Thermal Reset, 40° Ambient Temp, Suggested after-market replacement for: D848, HC37MB-730, 51PH124275, K055SWZ7989013B
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
| Voltage | 277/265V |
| Horsepower | 1/5 HP |
| RPM | 1040 |
| Enclosure | TEAO |
| Type | PSC (Permanent Split Capacitor) |
| Amperage | 1.3 Amps |
| Bearings | Sleeve Bearings |
| Speeds | 3-Speed |
| Rotation | Clockwise |
