sale
5450 Nidec | 1/6 hp 825 RPM 1-Speed 208-230V; 5.6" Blower Motor
5450 Nidec | 1/6 hp 825 RPM 1-Speed 208-230V; 5.6" Blower Motor
5450 Nidec | 1/6 hp 825 RPM 1-Speed 208-230V; 5.6" Blower Motor
5450 Nidec | 1/6 hp 825 RPM 1-Speed 208-230V; 5.6" Blower Motor
5450 Nidec | 1/6 hp 825 RPM 1-Speed 208-230V; 5.6" Blower Motor
5450 Nidec | 1/6 hp 825 RPM 1-Speed 208-230V; 5.6" Blower Motor

Nidec

5450 Nidec | 1/6 hp 825 RPM 1-Speed 208-230V; 5.6" Blower Motor

(No reviews) Write a Review
$233.45
$208.14
SKU 5450
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 1/6 HP
RPM 825
Type Permanent Split Capacitor
Amperage 1.3 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1/5 hp 1075 RPM 1-Speed 208-230V 1.3 amps
  • Shaft 1/2" x 3.688"
  • Rotation CW shaft end
  • 5.6" Diameter
  • Motor case length 3.812"
  • Sleeve bearings
  • 3MFD 370V Capacitor REQUIRED (Our Part #3DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Totally Enclosed Air Over Enclosure; Class B Insulation; 40C Ambient Temperature; 39" Leads. Application: outside condenser units. Suggested aftermarket replacements for Rheem 51-21854-02, 51-23055-11, K055SYH7997011B

Specifications
Voltage 208/230V
Horsepower 1/6 HP
RPM 825
Type Permanent Split Capacitor
Amperage 1.3 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Rotation Clockwise
Duty Continuous Duty
!
