119540.00 Leeson | 1.5 hp 1725 RPM 56 Frame TEFC 575V
119540.00 Leeson | 1.5 hp 1725 RPM 56 Frame TEFC 575V
119540.00 Leeson | 1.5 hp 1725 RPM 56 Frame TEFC 575V
119540.00 Leeson | 1.5 hp 1725 RPM 56 Frame TEFC 575V
119540.00 Leeson | 1.5 hp 1725 RPM 56 Frame TEFC 575V
119540.00 Leeson | 1.5 hp 1725 RPM 56 Frame TEFC 575V

Leeson

119540.00 Leeson | 1.5 hp 1725 RPM 56 Frame TEFC 575V

(No reviews) Write a Review
$805.00
$689.94
SKU 119540
UPC 6.63E+11
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 575V
Horsepower 1-1/2 HP
RPM 1725
Phase Three Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 1.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 1.5 hp 1725 RPM, 1.9 amps, 575 Volts, 60hz. - Three Phase
  • NEMA 56 Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.15 - overload protection = None
  • Reversible - Rigid Base Mount - Ball Bearings - Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a 575 Volt, three phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled.
Replaces Leeson # 110893.00

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 575V
Horsepower 1-1/2 HP
RPM 1725
Phase Three Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 1.9 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
!
