Leeson 114213.00 Electric Motor – 1.5 HP, 1725 RPM, 115/230V, 56 Frame

Leeson 114213.00

LEESON® AC Motor, Type TF Continuous Duty, Compressor Motors, Fan & Blower Motors Application, 4-Pole, B NEMA Design Special Features, 3/4 hp, 208 to 230/460 VAC, 2.6/1.3/2.9/1.4 A, 50/60 Hz Frequency, 1725/1425 rpm Speed, 1 Speed, Totally Enclosed Fan Cooled (TEFC) Enclosure, 56 Frame, 5/8 in Dia Shaft, Reversible Rotation, 1.149 Service Factor, Ball Bearing, Round Mounting, 40 deg C, Insulation Class: Class B, Rolled Steel, 11.31 in L Dimensions

Features:

• Standard, EPACT and premium efficiency Wattsaver® motor
• Shielded ball bearings for direct coupled applications
• Dynamically balanced rotors torques exceed NEMA performance standards

Specs:

• Type: Type TF Continuous Duty
• Material: Rolled Steel
• Dimensions: 11.31 in L
• Voltage Rating: 208 to 230/460 VAC
• Amperage Rating: 2.6/1.3/2.9/1.4 A
• Mounting Type: Round
• Frequency Rating: 50/60 Hz
• Speed: 1725/1425 rpm
• Enclosure Type: Totally Enclosed Fan Cooled (TEFC)
• Temperature Rating: 40 deg C
• Bearing Type: Ball
• Frame: 56
• Rotation: Reversible
• Number of Speeds: 1
• Horsepower: 3/4 hp
• Shaft Size: 5/8 in Dia
• Insulation Class: Class B
• Application Type: Compressor Motors, Fan & Blower Motors
• Special Features: 4-Pole, B NEMA Design
• Service Factor: 1.149
