FD32CM2P14 Nidec | 1.5 hp 1800 RPM 145T Frame TEFC (Farm Duty) 115/230V

FD32CM2P14 Nidec | 1.5 hp 1800 RPM 145T Frame TEFC (Farm Duty) 115/230V

This Nidec FD32CM2P14 motor is a 1.5 horsepower, 1800 RPM industrial motor designed for agricultural and farm-duty applications. It serves as a reliable replacement motor featuring a totally enclosed fan-cooled (TEFC) design for enhanced durability in demanding environments.

Key Specifications

• Horsepower: 1.5 hp
• RPM: 1800
• Voltage: 115/230 V, 60 Hz
• Amperage: 16.2/8.1 A
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 145T Frame, Flat Rigid Base Mount
• Shaft Dimensions: 7/8" Diameter x 2 1/4" Length
• Rotation: Electrically Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor includes a flat rigid base mount suitable for straightforward installation in existing NEMA 145T frame setups. It features manual overload protection and a service factor of 1.15, ensuring reliable operation under continuous duty at ambient temperatures up to 40°C. The motor’s reversible rotation capability allows flexible application in various agricultural equipment.

Warranty

1 Year Manufacturer Warranty
