1386 Nidec | 1/6 hp 1075 RPM 1-Speed 115V; 5.6" Blower Motor

1386 Nidec | 1/6 hp 1075 RPM 1-Speed 115V; 5.6" Blower Motor

This Nidec 1/6 horsepower blower motor operates at 1075 RPM with a single speed and 115V power supply. It is designed for HVAC applications requiring a reliable, continuous-duty motor with reversible rotation.

Key Specifications

• Horsepower: 1/6 hp
• RPM: 1075
• Voltage: 115V
• Amperage: 2.61 amps
• Enclosure: Totally Enclosed Air Over (TEAO)
• Frame / Diameter: 5.6" diameter
• Shaft Dimensions: 1/2" x 3.0"
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a resilient base mount for stable installation and includes a 7.5 MFD capacitor for permanent split capacitor operation. It is equipped with automatic overload protection and Class B insulation, suitable for continuous duty in ambient temperatures up to 40°C. The motor comes with 36" leads and is designed for 60 Hz operation.

Warranty

1 Year Manufacturer Warranty
