8906 Nidec | 1 hp 1075 RPM 3-Speed 115V; 5.6" Blower Motor

SKU:: 8906
UPC:
Weight:: 22.00 LBS
Width:: 6.00 (in)
Height:: 6.00 (in)
Depth:: 13.00 (in)
Shipping:: Free Shipping
ON SALE:: LIMITED TIME DISCOUNT
Voltage:: 115V
Horsepower:: 1 HP
RPM:: 1075
Type:: Permanent Split Capacitor
Amperage:: 12.1 Amps
Bearings:: Sleeve Bearings
Speeds:: 3-Speed
Insulation Class:: Class B
Rotation:: Reversible
Duty:: Continuous Duty

Current Stock:

Was: $230.00

Now: $205.84

Quantity:

Adding to cart… The item has been added

Description
Literature
Compliance & Restrictions

8906 Nidec | 1 hp 1075 RPM 3-Speed 115V; 5.6" Blower Motor

This 1 horsepower blower motor is designed for HVAC applications requiring reliable, continuous-duty performance. It replaces compatible motors with similar specifications and is ideal for systems needing a reversible rotation and multiple speed settings.

Key Specifications

Horsepower: 1 hp
RPM: 1075
Voltage: 115V
Amperage: 12.1 amps
Enclosure: Open Air Over
Frame / Diameter: 5.6" diameter, motor case length 6.062"
Shaft Dimensions: 0.5" diameter x 5.0" length
Rotation: Reversible
Bearings: Sleeve Bearings

Product Features & Fitment

This permanent split capacitor motor includes automatic overload protection and is rated for continuous duty with Class B insulation, suitable for ambient temperatures up to 40°C. It requires a 20 MFD 370V capacitor for operation and features 24" leads for easy wiring. The motor is designed for band and hub mounting, facilitating straightforward installation in compatible blower assemblies.
