1872 Nidec | 1/8 hp 825 RPM 1-Speed 208-230V; 5.6" Condenser Motor
1872 Nidec | 1/8 hp 825 RPM 1-Speed 208-230V; 5.6" Condenser Motor
1872 Nidec | 1/8 hp 825 RPM 1-Speed 208-230V; 5.6" Condenser Motor
1872 Nidec | 1/8 hp 825 RPM 1-Speed 208-230V; 5.6" Condenser Motor

Nidec

1872 Nidec | 1/8 hp 825 RPM 1-Speed 208-230V; 5.6" Condenser Motor

(No reviews) Write a Review
$192.05
$171.34
SKU 1872
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 1/8 HP
RPM 825
Type Permanent Split Capacitor
Amperage 0.8 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1/8 hp 825 RPM 1-Speed 208-230V 0.8 amps
  • Shaft 1/2" x 6"
  • Rotation = Reversible
  • 5.6" Diameter
  • Motor case length 4.1"
  • Sleeve bearings
  • 4 Holes in shell for Rheem Mounting
  • 5MFD 370V Capacitor REQUIRED (Our Part #5DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Totally Enclosed Air Over Enclosure; Class B Insulation; 60C Ambient Temperature; 30" Leads, K055SRB4513862B







Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230V
Horsepower 1/8 HP
RPM 825
Type Permanent Split Capacitor
Amperage 0.8 Amps
Bearings Sleeve Bearings
Speeds 1-Speed
Insulation Class Class B
Duty Continuous Duty
!
