T1C3JH Nidec | 1 hp 1140 RPM 56H TEFC 115/208-230V; 6.5" Nidec Electric Motor

This Nidec electric motor delivers reliable 1 horsepower performance at 1140 RPM, designed for various industrial and HVAC applications. It serves as a direct replacement for motors requiring a NEMA 56H frame with a TEFC enclosure and versatile voltage compatibility.

Key Specifications

• Horsepower: 1 hp
• RPM: 1140
• Voltage: 115/208-230V
• Amperage: 13.9/7.0 amps
• Enclosure: Totally Enclosed Fan Cooled (TEFC)
• Frame / Diameter: NEMA 56H Frame / 6.5" Diameter
• Shaft Dimensions: 5/8" diameter x 1 7/8" length; Shaft Height 3.5"
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base mount for secure installation and a motor case length of 11.75 inches, ensuring compatibility with standard mounting configurations. It includes a capacitor start design with automatic thermal protection, suitable for 40°C ambient temperatures and 60 Hz operation.

Warranty

1 Year Manufacturer Warranty
