1 hp 1800 RPM 143T Frame 115/208-230V Open Drip Nidec Electric Motor # D1C2J14

SKU:
D1C2J14
Weight:
32.00 LBS
Shipping:
Calculated at Checkout
$348.30
  • 1 hp 1800 RPM, 14.8/7.3 amps 115/208-230 Volts 60hz. Single Phase Motor
  • NEMA 143T frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • ODP; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Continuous Duty.  Wiring diagram on motor name plate. ODP = Open Drip Proof

C063JEL5315012B
