D1CM2J14 Nidec | 1 hp 1800 RPM 143T Frame 115/208-230V Open Drip Nidec Electric Motor
D1CM2J14 Nidec | 1 hp 1800 RPM 143T Frame 115/208-230V Open Drip Nidec Electric Motor
D1CM2J14 Nidec | 1 hp 1800 RPM 143T Frame 115/208-230V Open Drip Nidec Electric Motor
D1CM2J14 Nidec | 1 hp 1800 RPM 143T Frame 115/208-230V Open Drip Nidec Electric Motor

Nidec

D1CM2J14 Nidec | 1 hp 1800 RPM 143T Frame 115/208-230V Open Drip Nidec Electric Motor

(No reviews) Write a Review
$670.45
$598.58
SKU D1CM2J14
UPC 6.63E+11
Availability Subject to availability
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/208/230V
Horsepower 1 HP
RPM 1800
Phase Single Phase
Frame 143T
Enclosure ODP
Hertz 60 Hz
Amperage 14.8/7.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 1 hp 1800 RPM, 14.8/7.3 amps 115/208-230 Volts 60hz. Single Phase Motor
  • NEMA 143T frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • ODP; Service Factor: 1.15, Overload protection = Manual
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Continuous Duty.  Wiring diagram on motor name plate. ODP = Open Drip Proof

C063JEH5312012B

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 115/208/230V
Horsepower 1 HP
RPM 1800
Phase Single Phase
Frame 143T
Enclosure ODP
Hertz 60 Hz
Amperage 14.8/7.3 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class B
Mounting Rigid Base
Duty Continuous Duty
!
