HD1P2E Nidec | 1 hp 1800 RPM 143T Frame 230/460V TEFC Nidec Electric Motor

SKU:
HD1P2E
Weight:
60.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $341.00
Now: $304.30
Adding to cart… The item has been added
  • 1 hp 1800 RPM, 3.0/1.5 amps 230/460 Volts Three Phase Motor
  • NEMA 143T frame, Keyed Shaft 7/8" Diameter x 2 1/4"
  • Service Factor: 1.15 - overload protection = None
  • Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
  • "C" Dimension = 13.5"
  • 1 Year Manufacture Warranty

Hostile duty, premium efficient, world motor, cast iron frame. Corrosion resistant mill & chemical duty paint, stainless steel nameplate (with CE mark) & zinc plated hardware. Steel fan cover & conduit box, condensation drains with plastic plugs. Suitable for 20:1 variable torque; 5:1 constant torque on inverter power. Motor has a rigid base mount with a keyed shaft. Continuous Duty.  40C Ambient Temp. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled.

Model GG03, Replaces H1P2E
