Y548 Marathon 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready
Y548 Marathon 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready
Y548 Marathon 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready
Y548 Marathon 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready
Y548 Marathon 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready
Y548 Marathon 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready

Marathon

Y548 Marathon 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready

(No reviews) Write a Review
$4,617.14
$3,521.30
SKU Y548
UPC 7.23E+11
Availability LIMITED STOCK
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 10 HP
RPM 1200
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 28.0/14.0 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 10 hp 1200 RPM, 28.0/14.0 amps 230/460 Volts 60 Hz 3-Phase. Encoder Ready
  • NEMA 256TC Aluminum frame, C-face, Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.0, Overload protection = None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty

Inverter (Vector) duty three phase electric motor with a C-face mount. 1000:1 constant torque. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. TENV = Totally Enclosed Non-Ventilated. 256THTL5776

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 10 HP
RPM 1200
Phase Three Phase
Enclosure TENV
Hertz 60 Hz
Amperage 28.0/14.0 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class F
Mounting C-Face
!
