194011.00 Leeson SST Duck 20 hp 1800 RPM 208-230/460V 3-Phase 256TC Frame TEFC (base) Motor

358.00 LBS
Calculated at Checkout
Adding to cart… The item has been added
  • 20 hp 1800 RPM, 52.0-47.0/23.6 amps 208-230/460 Volts 60 Hz. Three Phase
  • NEMA 256TC frame, C-face, Stainless Steel Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base, Reversible, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty,

Full stainless steel exterior promotes resistance to water and chemical corrosion. This is a three phase electric motor with a C-face mount. Shaft has keyway. Motor has 4 threaded bolt holes on face for mounting a pump or gear head to the motor. Bolt holes are 5 7/8" on center measured across the shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan-Cooled. 194011.00
