1LPN5, 3M135 Dayton Direct Interchange 7 RPM 1/10 hp 115V Bison AC Parallel Shaft Gear Motor Model 013Q227-0250

1LPN5, 3M135 Dayton Direct Interchange 7 RPM 1/10 hp 115V Bison AC Parallel Shaft Gear Motor Model 013Q227-0250

This Bison AC Parallel Shaft Gear Motor is a direct OEM replacement for Dayton models 1LPN5 and 3M135, as well as Von Wiese V00212EV08. Designed for industrial applications requiring reliable low-speed operation, it delivers consistent performance at 7 RPM with 1/10 horsepower.

Key Specifications

• Horsepower: 1/10 hp
• RPM: 7
• Voltage: 115 V
• Amperage: 2.6 A
• Rotation: Clockwise facing shaft
• Shaft Dimensions: 5/8" diameter x 1-1/2" length, Woodruff keyed shaft

Product Features & Fitment

This motor features an internal cooling fan and is designed without a brake. It supports a load torque of 113 inch-pounds and can withstand an overhung load of up to 150 pounds on the shaft without internal damage. Note that the motor is not speed controllable. Installation requires consideration of the parallel shaft configuration and the clockwise rotation when facing the shaft.

Cross Reference

• Dayton 1LPN5, 3M135
• Von Wiese V00212EV08

Warranty

1 Year Manufacturer Warranty
