131509.00 Leeson | 2 hp 1725 RPM 182T Frame TEFC 115/208-230 Volts

SKU:
131509
Weight:
70.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNTED PRICES
Was: $818.00
Now: $730.20
  • 2 hp 1725 RPM, 24.8/12.4 amps 115/208-230 Volts 60hz. single Phase Motor
  • NEMA 182T Frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.0 - overload protection = None
  • Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
  • TEFC = Totally Enclosed Fan cooled.
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate.

C182C17FB11C, 131509.00
