D25P2H Nidec | 25 hp 1800 RPM 284T Frame 200V ODP Electric Motor Nidec
D25P2H Nidec | 25 hp 1800 RPM 284T Frame 200V ODP Electric Motor Nidec
D25P2H Nidec | 25 hp 1800 RPM 284T Frame 200V ODP Electric Motor Nidec
D25P2H Nidec | 25 hp 1800 RPM 284T Frame 200V ODP Electric Motor Nidec

Nidec

D25P2H Nidec | 25 hp 1800 RPM 284T Frame 200V ODP Electric Motor Nidec

(No reviews) Write a Review
$1,936.60
$1,728.80
SKU D25P2H
UPC 6.63E+11
Availability Subject to availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 284T
Enclosure ODP
Hertz 50/60 Hz
Amperage 67.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 25 hp 1800 RPM, 67.0 amps 200V, 50/60hz. Three Phase
  • NEMA 284T Frame Keyed Shaft 1 7/8" Diameter x 4 5/8"
  • ODP; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
  • "C" Dimension 23.2"
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor. Continuous Duty.  Premium efficient. 40C Ambient Temp. Wiring diagram on motor name plate. ODP = Open Drip Proof

Model DB97, Dayton 263L69

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 284T
Enclosure ODP
Hertz 50/60 Hz
Amperage 67.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
!
