sale
Marathon
GT1027A Marathon 25 hp 3600 RPM 284TS Frame 208-230/460V TEFC Marathon Electric Motor
(No reviews)
Write a Review
Write a Review
Marathon
GT1027A Marathon 25 hp 3600 RPM 284TS Frame 208-230/460V TEFC Marathon Electric Motor
$2,151.42
$1,828.50
SKU
MGT1027
Availability
Motor may have "A" suffix
Shipping
Calculated at Checkout
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
Voltage
208/230/460V
Horsepower
25 HP
RPM
3600
Phase
Three Phase
Frame
284TS
Enclosure
TEFC
Hertz
60 Hz
Amperage
60.0/30.0 Amps
Bearings
Ball Bearings
Service Factor
1.15
Insulation Class
Class F
Mounting
Rigid Base
- 25 hp 3600 RPM, 60.0/30.0 amps 208-230/460 Volts 60hz. Three Phase Motor
- NEMA 284TS Frame Keyed Shaft 1 5/8 " Diameter x 3 1/4"
- Service Factor: 1.15 - overload protection = None
- Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
- 1 Year Manufacture Warranty
General purpose motor can be used for many applications requiring a three phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled.
284TSTFCD6001 Replaces Leeson 170035.60, 199021.00, B199021.00; Dayton 44Z348
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
| Voltage | 208/230/460V |
| Horsepower | 25 HP |
| RPM | 3600 |
| Phase | Three Phase |
| Frame | 284TS |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 60.0/30.0 Amps |
| Bearings | Ball Bearings |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
