LX7930 Nidec | 3/4 hp 1075 RPM 3-Speed 460V; 5.6" Blower Motor

LX7930 Nidec 3/4 hp 1075 RPM 3-Speed 460V 5.6" Blower Motor

This 3/4 horsepower blower motor is designed for HVAC applications requiring a reliable 3-speed motor with a 1075 RPM rating. It serves as a suggested aftermarket replacement for Lennox models 43G5201, 43G52, K55HXEKA-7371, K55HXDUX-1258, and K055DUS1258011B.

Key Specifications

• Horsepower: 3/4 hp
• RPM: 1075
• Voltage: 460V
• Amperage: 2.3 amps
• Enclosure: Open
• Frame / Diameter: 5.6" diameter, 5.3" motor case length
• Shaft Dimensions: 1/2" diameter x 2.2" length
• Rotation: Clockwise (CW) shaft end
• Bearings: Sleeve bearings

Product Features & Fitment

This permanent split capacitor motor features automatic overload protection and is rated for continuous duty with Class B insulation, suitable for ambient temperatures up to 40°C. It includes resilient rings and 36" leads for easy wiring. A 20 MFD 370V capacitor (Part #20DV) is required for operation but sold separately.

Cross Reference

• Lennox 43G5201, 43G52, K55HXEKA-7371, K55HXDUX-1258, K055DUS1258011B

Warranty

1 Year Manufacturer Warranty
