8904 Nidec | 3/4 hp 1075 RPM 3-Speed 115V; 5.6" Blower Motor

8904 Nidec | 3/4 hp 1075 RPM 3-Speed 115V; 5.6" Blower Motor

This 3/4 horsepower blower motor is designed for HVAC applications requiring a reliable, three-speed motor. It is a direct replacement compatible with Century DL1026 and Fasco D728 models, providing efficient and consistent airflow.

Key Specifications

• Horsepower: 3/4 hp
• RPM: 1075
• Voltage: 115V
• Amperage: 9.5 amps
• Frame / Diameter: 5.6" diameter
• Shaft Dimensions: 0.5" x 5.0"
• Rotation: Reversible
• Bearings: Sleeve Bearings
• Enclosure: Open Air Over

Product Features & Fitment

This permanent split capacitor motor includes automatic overload protection and is rated for continuous duty with Class B insulation, suitable for ambient temperatures up to 40°C. It features a resilient ring mount and comes with 24" leads for easy wiring. A 15 MFD 370V capacitor (Part #15DV) is required but not included. The motor case length measures 5.9" and it does not have shaft extensions.

Warranty

1 Year Manufacturer Warranty
