3340 Nidec | 3/4 hp 1075 RPM 4-Speed 115V; 5.6" Blower Motor

3340 Nidec | 3/4 hp 1075 RPM 4-Speed 115V; 5.6" Blower Motor

SKU:
3340
Weight:
20.00 LBS
Width:
6.00 (in)
Height:
6.00 (in)
Depth:
12.50 (in)
Shipping:
Free Shipping
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
115V
Horsepower:
3/4 HP
RPM:
1075
Type:
Permanent Split Capacitor
Amperage:
12.1 Amps
Speeds:
4-Speed
Insulation Class:
Class B
Duty:
Continuous Duty
Was: $472.65
Now: $422.17
Adding to cart… The item has been added
  • 3/4 hp 1075 RPM 4-Speed 115V 12.1 amps
  • Shaft 1/2" x 6.0"
  • Rotation = Reversible
  • 5.6" Diameter
  • Motor case length 5.31"
  • Slevee bearings
  • Resilient rings
  • 7.5MFD 370V Capacitor REQUIRED (Our Part #7.5DV)
  • 1 Year mfg warranty

Permanent Split Capacitor Motor. Automatic Overload Protection. Continuous Duty; Open Enclosure; Class B Insulation; 40C Ambient Temperature; 27" Leads. Application: Heat Pump, Furnace. K055SWW7987012B. Carrier D838, HC45SE116, SC435X101, HC435SE116

!
