C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor
C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor

Marathon

C271 Marathon 3/4 hp 1200 RPM 56 Frame 115/230V Totally Enclosed Marathon Electric Motor

(No reviews) Write a Review
$914.60
$769.95
SKU MC271
Shipping Free Shipping
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 115/230V
Horsepower 3/4 HP
RPM 1200
Phase Single Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 10.6/5.3 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class B
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 3/4 hp 1200 RPM, 10.6/5.3 amps 115/230 Volts 60hz. Capacitor Start/Run Motor
  • NEMA 56 Frame Keyed Shaft 5/8" Diameter x 1 7/8"
  • Service Factor: 1.0, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class B Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a single phase electric motor. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled

Marathon Model: 5KCR48WN6066

Replaces Leeson 110400.00

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE DISCOUNTED PRICES & SHIPS SAME DAY FOR ORDERS PLACED BEFORE 2 PM
Voltage 115/230V
Horsepower 3/4 HP
RPM 1200
Phase Single Phase
Frame 56
Enclosure TEFC
Hertz 60 Hz
Amperage 10.6/5.3 Amps
Bearings Ball Bearings
Service Factor 1.0
Insulation Class Class B
Mounting Rigid Base
!
