D34P2AH9 Nidec | 3/4 hp 1800 RPM 56H Frame 208-230/460V Open Drip Nidec Electric Motor

D34P2AH9 Nidec 3/4 hp 1800 RPM 56H Frame Open Drip Electric Motor

This Nidec 3/4 horsepower electric motor is designed for general-purpose industrial applications requiring a reliable three-phase motor. It replaces similar 56H frame motors and is suitable for various equipment needing a resilient base mount.

Key Specifications

• Horsepower: 3/4 hp
• RPM: 1800
• Voltage: 208-230/460 V
• Amperage: 2.7/1.4 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56H Frame
• Shaft Dimensions: 5/8" Diameter x 1 7/8" Length, keyed
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a resilient base mount for stable installation and includes ball bearings for smooth operation. It has Class B insulation and a service factor of 1.25 but does not include overload protection. The wiring diagram is conveniently located on the motor nameplate to assist with proper electrical connections.

Warranty

1 Year Manufacturer Warranty
