D3P2G Nidec | 3 hp 1800 RPM 182T Frame 575V ODP Motor Electric Motor Nidec
D3P2G Nidec | 3 hp 1800 RPM 182T Frame 575V ODP Motor Electric Motor Nidec
D3P2G Nidec | 3 hp 1800 RPM 182T Frame 575V ODP Motor Electric Motor Nidec
D3P2G Nidec | 3 hp 1800 RPM 182T Frame 575V ODP Motor Electric Motor Nidec

Nidec

D3P2G Nidec | 3 hp 1800 RPM 182T Frame 575V ODP Motor Electric Motor Nidec

(No reviews) Write a Review
$509.45
$455.17
SKU D3P2G
UPC 6.63E+11
Availability Subject to availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182T
Enclosure ODP
Hertz 50/60 Hz
Amperage 3.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
Adding to cart… The item has been added
Description
  • 3 hp 1800 RPM, 3.1 amps 575 Volts 50/60hz. Three Phase
  • NEMA 182T frame Keyed Shaft 1-1/8" x 2 3/4"
  • ODP; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor. Continuous Duty.  Premium efficient. 40C Ambient Temp. Wiring diagram on motor name plate. ODP = Open Drip Proof

Model FH80, Dayton 6YV42

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182T
Enclosure ODP
Hertz 50/60 Hz
Amperage 3.1 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
!
