D3P2H Nidec | 3 hp 1800 RPM 182T Frame 200V ODP Motor Electric Motor Nidec
D3P2H Nidec | 3 hp 1800 RPM 182T Frame 200V ODP Motor Electric Motor Nidec
D3P2H Nidec | 3 hp 1800 RPM 182T Frame 200V ODP Motor Electric Motor Nidec
D3P2H Nidec | 3 hp 1800 RPM 182T Frame 200V ODP Motor Electric Motor Nidec

Nidec

D3P2H Nidec | 3 hp 1800 RPM 182T Frame 200V ODP Motor Electric Motor Nidec

(No reviews) Write a Review
$509.45
$407.95
SKU D3P2H
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182T
Enclosure ODP
Amperage 8.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
Cross Reference HE21 PJ2AA42A01C TO117 Part May Require lead time, please call for availability Ships via Freight Truck Only, please provide a delivery address that allows for semi truck for deliveries
Adding to cart… The item has been added
Description
  • 3 hp 1800 RPM, 8.8 amps 200 Volts Three Phase
  • NEMA 182T frame Keyed Shaft 1-1/8" x 2 3/4"
  • ODP; Service Factor: 1.15, Overload protection = None
  • Reversible, Rigid Base Mount, Ball Bearings, Class F Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase electric motor. Continuous Duty.  Premium efficient. 40C Ambient Temp. Wiring diagram on motor name plate. ODP = Open Drip Proof

Model FH78, Dayton 6YV43

Specifications
Voltage 200V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Frame 182T
Enclosure ODP
Amperage 8.8 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Continuous Duty
Cross References

HE21 PJ2AA42A01C TO117 Part May Require lead time, please call for availability Ships via Freight Truck Only, please provide a delivery address that allows for semi truck for deliveries

!
