GT0072 Marathon 40 hp 3550 RPM 286TS Frame 208-230/460 Volts Open Drip Electric Motor
GT0072 Marathon 40 hp 3550 RPM 286TS Frame 208-230/460 Volts Open Drip Electric Motor
GT0072 Marathon 40 hp 3550 RPM 286TS Frame 208-230/460 Volts Open Drip Electric Motor
GT0072 Marathon 40 hp 3550 RPM 286TS Frame 208-230/460 Volts Open Drip Electric Motor
GT0072 Marathon 40 hp 3550 RPM 286TS Frame 208-230/460 Volts Open Drip Electric Motor
GT0072 Marathon 40 hp 3550 RPM 286TS Frame 208-230/460 Volts Open Drip Electric Motor

Marathon

GT0072 Marathon 40 hp 3550 RPM 286TS Frame 208-230/460 Volts Open Drip Electric Motor

(No reviews) Write a Review
$3,156.24
$2,059.95
SKU MGT0072
Availability Subject to Availability
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 40 HP
RPM 3550
Phase Three Phase
Frame 286TS
Enclosure ODP
Hertz 60 Hz
Amperage 93.0/46.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description



  • 40 hp 3600 RPM, 93.0/46.5 amps 230/460 Volts 60hz. Three Phase Motor
  • NEMA 286TS Frame Keyed Shaft 1 5/8 " Diameter x 3 1/4"
  • Service Factor: 1.15 - overload protection = None
  • Reversible - Rigid Base Mount - Ball Bearings - Class F Insulation
  • 1 Year Manufacture Warranty

General purpose motor can be used for many applications requiring a three phase Electric motor. Motor has a rigid base mount with a keyed shaft. Wiring diagram on motor name plate. ODP = Open Drip Proof.

286TSTDBD6001 Replaces Leeson 170038.60, B199710.00, 199710.00; Dayton 454X63

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 40 HP
RPM 3550
Phase Three Phase
Frame 286TS
Enclosure ODP
Hertz 60 Hz
Amperage 93.0/46.5 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
