9038B Marathon 5 hp (1 speed) 230V 3600 RPM ODP 56H Frame Cap Start/Run Pressure Washer Motor

9038B Marathon 5 hp (1 speed) 230V 3600 RPM ODP 56H Frame Cap Start/Run Pressure Washer Motor

The 9038B Marathon motor is a 5 horsepower, single-speed motor designed for pressure washer units, specifically replacing motors used in air compressors with horizontal shaft orientation. It features a capacitor start and run design for reliable performance in demanding applications.

Key Specifications

• Horsepower: 5 hp
• RPM: 3600
• Voltage: 230 V
• Amperage: 19.6 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56H
• Shaft Dimensions: 1 7/8" length x 5/8" diameter
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rigid base for stable mounting and manual thermal protection. It is designed for horizontal shaft installation and includes Class B insulation for durability. The reversible rotation capability allows flexible integration into various pressure washer configurations.

Warranty

1 Year Manufacturer Warranty
