AQUA-SHIELD US ELECTRIC MOTOR
- 1/2 HP 3450 RPM 8.2/4.1 amps, 115/230V 60hz
- 0.65 THP (Total Horsepower)
- Automatic Overload Protection
- Non-Reversible - CCW Rotation facing the shaft
- C-Face Mount, Round Body-no base
- 48Y Frame-Square Flange; 5/8" diameter threaded stainless steel shaft
48Y Square Flange replacement pool motor. Motor is found on many in ground pool pumps such as Sta-Rite Max-E Glas, Dura Glas, Dyna Glas.
Motor has a square type flange for mounting the pump. 4 non-threaded bolts holes in flange. 48Y motors do not have internal threaded hole in shaft.
Standard 1081 pump duty motor. Stainless steel shaft. Sealed ball bearings. 1 year warranty
Model C055FDG2160013J
Replaces EUSQ1052
Effective July 19, 2021 the US Dept of Energy regulations on single speed, two-speed and booster pumps go into effect.
Please check your local and State codes to comply with their requirements for replacement pump motors.
Click here to help answer more questions
ATTENTION: Shipping Restrictions Apply!
California: This replacement pump motor does not comply with California's Efficiency Regulations. These regulations can be found in Title 20, in the California Code of Regulations (CCR) sections 1601-1609. To meet California’s requirement, the replacement pump motor must be a variable speed.
To comply with current and upcoming regulations we recommend upgrading now to a variable speed motor.
We recommend using Century EVQ130 1.30THP Variable Speed Motor
