BMU3P2DCR Nidec 3 hp 1800 RPM 182TC (No Base) 208-230/460V TEFC 3-Phase BrakeMotor
BMU3P2DCR Nidec 3 hp 1800 RPM 182TC (No Base) 208-230/460V TEFC 3-Phase BrakeMotor
BMU3P2DCR Nidec 3 hp 1800 RPM 182TC (No Base) 208-230/460V TEFC 3-Phase BrakeMotor
BMU3P2DCR Nidec 3 hp 1800 RPM 182TC (No Base) 208-230/460V TEFC 3-Phase BrakeMotor

Nidec

BMU3P2DCR Nidec 3 hp 1800 RPM 182TC (No Base) 208-230/460V TEFC 3-Phase BrakeMotor

(No reviews) Write a Review
$2,783.00
$2,485.04
SKU BMU3P2DCR
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Enclosure TEFC
Hertz 60 Hz
Amperage 7.8/3.9 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting C-Face
Adding to cart… The item has been added
Description
  • 3 hp 1800 RPM, 8.4-7.8/3.9 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 182TC Aluminum Frame, Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.25 Overload protection = None
  • Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For use on conveyors, machine tools, doors and any application requiring quick stops and a C-Face motor. NEMA design B. Brake provisions. Wiring diagram on motor name plate. TEFC = Totally-Enclosed Fan-Cooled. FR34

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 3 HP
RPM 1800
Phase Three Phase
Enclosure TEFC
Hertz 60 Hz
Amperage 7.8/3.9 Amps
Bearings Ball Bearings
Service Factor 1.25
Insulation Class Class F
Mounting C-Face
!
