C1458 Marathon 1/2 hp 115/230V 1800 RPM ODP 56 Frame Instant Reversiing Motor

C1458 Marathon 1/2 hp 115/230V 1800 RPM ODP 56 Frame Instant Reversing Motor

This Marathon 1/2 horsepower motor is designed for applications requiring fast motor reversals. It features a durable open drip proof (ODP) enclosure and is ideal for replacing or upgrading motors in HVAC and industrial equipment.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 115/230 V, 60 Hz
• Amperage: 8.8/4.4 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56 Frame
• Shaft Dimensions: 1 7/8" length x 5/8" diameter
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor includes a capacitor start and operates at a single speed with a service factor of 1.25. It is designed for horizontal shaft installation and features a rigid base for secure mounting. Thermal protection is not included.

Warranty

1 Year Manufacturer Warranty
