C30P1FSCR Nidec 25 hp 1800 RPM 286TSC Frame (Vertical) 460V TEFC 3-Phase C-Face Motor
C30P1FSCR Nidec 25 hp 1800 RPM 286TSC Frame (Vertical) 460V TEFC 3-Phase C-Face Motor
C30P1FSCR Nidec 25 hp 1800 RPM 286TSC Frame (Vertical) 460V TEFC 3-Phase C-Face Motor
C30P1FSCR Nidec 25 hp 1800 RPM 286TSC Frame (Vertical) 460V TEFC 3-Phase C-Face Motor

Nidec

C30P1FSCR Nidec 25 hp 1800 RPM 286TSC Frame (Vertical) 460V TEFC 3-Phase C-Face Motor

(No reviews) Write a Review
$3,904.25
$3,486.34
SKU C30P1FSCR
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 286TSC
Enclosure TEFC
Hertz 50/60 Hz
Amperage 34.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 30 hp 3600 RPM, 34.0 amps 460 Volts 50/60 Hz Three Phase Motor
  • NEMA 286TSC cast iron frame, Keyed Shaft 1 5/8" Diameter x 3 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Vertical C-Face Mount, Regreasable Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Three phase motor designed for chemically corrosive environments with either 50 or 60 Hz power. Inverter Duty. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. DW85

Specifications
Voltage 460V
Horsepower 25 HP
RPM 1800
Phase Three Phase
Frame 286TSC
Enclosure TEFC
Hertz 50/60 Hz
Amperage 34.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting C-Face
Duty Inverter Duty
!
