CD30P3F Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 460V TEFC 3-Phase World Electric Motor
CD30P3F Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 460V TEFC 3-Phase World Electric Motor
CD30P3F Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 460V TEFC 3-Phase World Electric Motor
CD30P3F Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 460V TEFC 3-Phase World Electric Motor

Nidec

CD30P3F Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 460V TEFC 3-Phase World Electric Motor

(No reviews) Write a Review
$3,987.05
$3,559.71
SKU CD30P3F
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 460V
Horsepower 30 HP
RPM 1200
Phase Three Phase
Frame 326T
Enclosure TEFC
Hertz 50/60 Hz
Amperage 35.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 30 hp 1200 RPM, 35.0 amps 460 Volts 50/60 Hz Three Phase Motor
  • NEMA 324T Cast Iron frame Keyed Shaft 2 1/8" Diameter x 5 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Regreasable Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

Hostile duty three phase motor designed for chemically corrosive environments with either 50 or 60 Hz power. Inverter Duty. Self-certified Class 1, Division 2, Groups A, B, C, D. Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan cooled. GC31

Specifications
Voltage 460V
Horsepower 30 HP
RPM 1200
Phase Three Phase
Frame 326T
Enclosure TEFC
Hertz 50/60 Hz
Amperage 35.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
