D30P3H Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor
D30P3H Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor
D30P3H Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor
D30P3H Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor

Nidec

D30P3H Nidec 30 hp 1200 RPM 326T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$3,174.00
$2,833.72
SKU D30P3H
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 30 HP
RPM 1200
Phase Three Phase
Frame 326T
Enclosure ODP
Hertz 60 Hz
Amperage 81 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 30 hp 1200 RPM, 81 amps 200 Volts 60 Hz Three Phase Motor
  • NEMA 326T Rolled Steel Frame, Keyed Shaft 2 1/8" Diameter x 5 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. DC25

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 30 HP
RPM 1200
Phase Three Phase
Frame 326T
Enclosure ODP
Hertz 60 Hz
Amperage 81 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
