D20P3H Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor
D20P3H Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor
D20P3H Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor
D20P3H Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor

Nidec

D20P3H Nidec 20 hp 1200 RPM 286T Frame (Rigid Base) 200V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$2,518.50
$2,248.83
SKU D20P3H
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 20 HP
RPM 1200
Phase Three Phase
Frame 286T
Enclosure ODP
Hertz 60 Hz
Amperage 56.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 20 hp 1200 RPM, 56.0 amps 200 Volts 60 Hz Three Phase Motor
  • NEMA 286T Rolled Steel Frame, Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. DB91

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 20 HP
RPM 1200
Phase Three Phase
Frame 286T
Enclosure ODP
Hertz 60 Hz
Amperage 56.0 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
