Coleman-Mach 8330-752 | Cool-Only Control Package for Non-Ducted RV Air Conditioners

8330-752 Coleman-Mach Standard Cool-Only Control Box

The Coleman-Mach 8330-752 is an OEM multi-speed internal control box designed to bridge communications between a wall-mounted analog thermostat and a compatible rooftop air conditioner. It is engineered to deliver reliable, centralized relays for standard single-zone ducted recreational vehicle systems.

Key Specifications

• System Application: Single-Zone Ducted Layouts
• Operational Mode: Cooling Only
• Control Circuit Input: 12 VDC
• Line Voltage Power: 115 VAC / 60 Hz
• Fan Controls: Dual Speed
• Heat Strip Ready: No (Strictly Cool-Only Configuration)
• Dimensions: 10". (L) x 4.50". (W) x 3" (H)
• Weight: 2.10 lbs.

Product Features & Fitment

This heavy-duty metal control housing encloses premium electrical contactors and multi-speed relays engineered to handle the inductive start-up loads of high-capacity RV compressors. By cleanly translating low-voltage 12V DC signals from the wall into line-voltage 115V AC operational power, it ensures safe, efficient cycling of the primary cooling assets without risking dashboard grid drops. It comes pre-wired with an integrated quick-connect wiring harness that plugs directly into the rooftop unit's junction port, eliminating raw-wire splicing inside the ceiling plenum.
