sale
Nidec
CW15V2E2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor
(No reviews)
Write a Review
Write a Review
Nidec
CW15V2E2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor
$2,680.65
$2,393.38
SKU
CW15V2E2
Shipping
Calculated at Checkout
Compliance Tab
/content/product_tabs/p65warnings.html
ON SALE
LIMITED TIME DISCOUNT
Voltage
230/460V
Horsepower
15 HP
RPM
1800
Phase
Three Phase
Frame
254T
Enclosure
TEFC
Hertz
60 Hz
Amperage
20.6 Amps
Bearings
Ball Bearings
Speeds
1-Speed
Service Factor
1.15
Insulation Class
Class F
Mounting
Rigid Base
Duty
Inverter Duty
CW15V2E2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor
This Nidec CW15V2E2 motor is a 15 horsepower, 1800 RPM, three-phase motor designed specifically for cooling tower and evaporation cooler applications. It serves as a reliable replacement motor, offering corrosion resistance and inverter duty capability for variable speed operation.
Key Specifications
- Horsepower: 15 hp
- RPM: 1800
- Voltage: 230/460 V
- Amperage: 41.0/20.6 A
- Enclosure: TEFC (Totally Enclosed Fan Cooled)
- Frame / Diameter: NEMA 254T Cast Iron Frame
- Shaft Dimensions: Keyed Shaft, 1 5/8" Diameter x 4" Length
- Rotation: Reversible
- Bearings: Ball Bearings
Product Features & Fitment
The motor features a rigid base mount for secure installation and is constructed with Class F insulation for enhanced thermal protection. It is inverter duty rated with a 10:1 speed range, allowing for flexible speed control. Wiring diagrams are provided on the motor nameplate to assist with proper electrical connections.
Warranty
1 Year Manufacturer Warranty
1 Year Manufacturer Warranty
| Compliance Tab | /content/product_tabs/p65warnings.html |
|---|---|
| ON SALE | LIMITED TIME DISCOUNT |
| Voltage | 230/460V |
| Horsepower | 15 HP |
| RPM | 1800 |
| Phase | Three Phase |
| Frame | 254T |
| Enclosure | TEFC |
| Hertz | 60 Hz |
| Amperage | 20.6 Amps |
| Bearings | Ball Bearings |
| Speeds | 1-Speed |
| Service Factor | 1.15 |
| Insulation Class | Class F |
| Mounting | Rigid Base |
| Duty | Inverter Duty |
