CW15V2H2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 200V TEFC 3-Phase Cooling Tower Motor
CW15V2H2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 200V TEFC 3-Phase Cooling Tower Motor
CW15V2H2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 200V TEFC 3-Phase Cooling Tower Motor
CW15V2H2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 200V TEFC 3-Phase Cooling Tower Motor

Nidec

CW15V2H2 Nidec 15 hp 1800 RPM 254T Frame (Rigid Base) 200V TEFC 3-Phase Cooling Tower Motor

(No reviews) Write a Review
$2,680.65
$2,393.38
SKU CW15V2H2
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 15 HP
RPM 1800
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Amperage 41.0 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
Adding to cart… The item has been added
Description
  • 15 hp 1800 RPM, 41.0 amps 200 Volts 60 Hz Three Phase Motor
  • NEMA 254T Cast Iron frame Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For use in cooling tower and evaporation cooler applications. Corrosion resistant, Inverter Duty (10:1 speed range). Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. GM49

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 200V
Horsepower 15 HP
RPM 1800
Phase Three Phase
Frame 254T
Enclosure TEFC
Hertz 60 Hz
Amperage 41.0 Amps
Bearings Ball Bearings
Speeds 1-Speed
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Duty Inverter Duty
!
