CW5V2E2 Nidec 5 hp 1800 RPM 184T Frame (Rigid Base) 230/460V TEFC 3-Phase Cooling Tower Motor

SKU:
CW5V2E2
Weight:
110.00 LBS
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Was: $1,031.00
Now: $920.90
Adding to cart… The item has been added
  • 5 hp 1800 RPM, 12.7/6.3 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 184T Cast Iron frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For use in cooling tower and evaporation cooler applications. Corrosion resistant, Inverter Duty (10:1 speed range). Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan CooledGM38
