HW5V2G2 Nidec 5 hp 1800 RPM 184T Frame (Rigid Base) 575V TEFC 3-Phase Cooling Tower Motor

HW5V2G2 Nidec 5 hp 1800 RPM 184T Frame (Rigid Base) 575V TEFC 3-Phase Cooling Tower Motor

SKU:
HW5V2G2
Weight:
110.00 LBS
Width:
18.00 (in)
Height:
14.00 (in)
Depth:
14.00 (in)
Shipping:
Calculated at Checkout
ON SALE:
LIMITED TIME DISCOUNT
Voltage:
575V
Horsepower:
5 HP
RPM:
1800
Phase:
Three Phase
Frame:
184T Frame
Enclosure:
TEFC
Hertz:
60 Hz
Amperage:
5.0 Amps
Bearings:
Ball Bearings
Speeds:
1-Speed
Service Factor:
1.15
Insulation Class:
Class F
Mounting:
Rigid Base
Duty:
Inverter Duty
Was: $1,185.65
Now: $1,059.04
Adding to cart… The item has been added
  • 5 hp 1800 RPM, 5.0 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 184T Cast Iron frame Keyed Shaft 1 1/8" Diameter x 2 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

For use in cooling tower and evaporation cooler applications. Corrosion resistant, Inverter Duty (10:1 speed range). Wiring diagram on motor name plate. TEFC = Totally Enclosed Fan Cooled. FH39

!
