D10P4D Nidec 10 hp 900 RPM 284T Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor
D10P4D Nidec 10 hp 900 RPM 284T Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor
D10P4D Nidec 10 hp 900 RPM 284T Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor
D10P4D Nidec 10 hp 900 RPM 284T Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

Nidec

D10P4D Nidec 10 hp 900 RPM 284T Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$2,856.60
$2,550.24
SKU D10P4D
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 900
Phase Three Phase
Frame 284T
Enclosure ODP
Hertz 60 Hz
Amperage 29.2/14.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 10 hp 900 RPM, 31.0-29.2/14.6 amps 208-230/460 Volts 60 Hz Three Phase Motor
  • NEMA 284T Rolled Steel Frame, Keyed Shaft 1 5/8" Diameter x 4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. FR36

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 10 HP
RPM 900
Phase Three Phase
Frame 284T
Enclosure ODP
Hertz 60 Hz
Amperage 29.2/14.6 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
