D111 Marathon 1/2 hp (1 speed) 115/230V 1800 RPM ODP 56 Frame Cap Start Resilient Base Motor

D111 Marathon 1/2 hp (1 speed) 115/230V 1800 RPM ODP 56 Frame Cap Start Resilient Base Motor

The D111 Marathon motor is a 1/2 horsepower, single-speed blower motor designed for air circulation applications in residential and commercial buildings. It serves as a reliable replacement for standard blower motors requiring a capacitor start and resilient base mounting.

Key Specifications

• Horsepower: 1/2 hp
• RPM: 1800
• Voltage: 115/230V, 60 Hz
• Amperage: 7.2/3.6 amps
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 56 Frame
• Shaft Dimensions: 1 7/8" length x 5/8" diameter, keyed
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a capacitor start and a resilient base for vibration reduction and secure mounting. It is designed for flexible installation with a reversible shaft orientation, suitable for both vertical and horizontal shaft positions. The motor includes ball bearings for enhanced durability and operates with Class B insulation.

Warranty

1 Year Manufacturer Warranty
