D25P4E Nidec 25 hp 900 RPM 326T Frame (Rigid Base) 230/460V ODP 3-Phase Electric Motor
D25P4E Nidec 25 hp 900 RPM 326T Frame (Rigid Base) 230/460V ODP 3-Phase Electric Motor
D25P4E Nidec 25 hp 900 RPM 326T Frame (Rigid Base) 230/460V ODP 3-Phase Electric Motor
D25P4E Nidec 25 hp 900 RPM 326T Frame (Rigid Base) 230/460V ODP 3-Phase Electric Motor

Nidec

D25P4E Nidec 25 hp 900 RPM 326T Frame (Rigid Base) 230/460V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$4,471.20
$3,992.46
SKU D25P4E
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 25 HP
RPM 900
Phase Three Phase
Frame 326T
Enclosure ODP
Hertz 60 Hz
Amperage 67/33 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 25 hp 900 RPM, 67/33 amps 230/460 Volts 60 Hz Three Phase Motor
  • NEMA 324T Rolled Steel Frame, Keyed Shaft 2 1/8" Diameter x 5 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. FS84

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 230/460V
Horsepower 25 HP
RPM 900
Phase Three Phase
Frame 326T
Enclosure ODP
Hertz 60 Hz
Amperage 67/33 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
