sale
D50P1DSC Nidec 50 hp 3600 RPM 324TSC Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor
D50P1DSC Nidec 50 hp 3600 RPM 324TSC Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor
D50P1DSC Nidec 50 hp 3600 RPM 324TSC Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor
D50P1DSC Nidec 50 hp 3600 RPM 324TSC Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

Nidec

D50P1DSC Nidec 50 hp 3600 RPM 324TSC Frame (Rigid Base) 208-230/460V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$3,303.95
$2,950.10
SKU D50P1DSC
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 324TSC
Enclosure ODP
Hertz 50/60 Hz
Amperage 117/59 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 50 hp 3600 RPM, 130-117/59 amps 208-230/460 Volts 50/60 Hz Three Phase Motor
  • NEMA 324TSC frame Keyed Shaft 1 8/8" Diameter x 3 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount, Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose C-Face motor can be used for many applications requiring a three phase electric motor. Wiring diagram on motor name plate. ODP = Open Drip Proof. DC34

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 208/230/460V
Horsepower 50 HP
RPM 3600
Phase Three Phase
Frame 324TSC
Enclosure ODP
Hertz 50/60 Hz
Amperage 117/59 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
