D50P2G Nidec 50 hp 1800 RPM 326T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D50P2G Nidec 50 hp 1800 RPM 326T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D50P2G Nidec 50 hp 1800 RPM 326T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D50P2G Nidec 50 hp 1800 RPM 326T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor

Nidec

D50P2G Nidec 50 hp 1800 RPM 326T Frame (Rigid Base) 575V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$2,961.25
$2,643.97
SKU D50P2G
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326T
Enclosure ODP
Hertz 60 Hz
Amperage 46 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 50 hp 1800 RPM, 46 amps 575 Volts 60 Hz Three Phase Motor
  • NEMA 326T Rolled Steel Frame, Keyed Shaft 2 1/8" Diameter x 5 1/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. R364

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326T
Enclosure ODP
Hertz 60 Hz
Amperage 46 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
