D50P2GS Nidec 50 hp 1800 RPM 326TS Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D50P2GS Nidec 50 hp 1800 RPM 326TS Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D50P2GS Nidec 50 hp 1800 RPM 326TS Frame (Rigid Base) 575V ODP 3-Phase Electric Motor
D50P2GS Nidec 50 hp 1800 RPM 326TS Frame (Rigid Base) 575V ODP 3-Phase Electric Motor

Nidec

D50P2GS Nidec 50 hp 1800 RPM 326TS Frame (Rigid Base) 575V ODP 3-Phase Electric Motor

(No reviews) Write a Review
$2,961.25
$2,643.97
SKU D50P2GS
Shipping Calculated at Checkout
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326TS
Enclosure ODP
Hertz 60/50 Hz
Amperage 45 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
Adding to cart… The item has been added
Description
  • 50 hp 1800 RPM, 45 amps 575 Volts 60/50 Hz Three Phase Motor
  • NEMA 326TS Rolled Steel Frame, Keyed Shaft 1 7/8" Diameter x 3 3/4"
  • Service Factor: 1.15, Overload protection = None
  • Rigid Base Mount,  Ball Bearings, Class F Insulation, Reversible
  • 1 Year Manufacture Warranty

General purpose motor designed for use with pumps, fans, and compressors where contaminants are minimal. Wiring diagram on motor name plate. ODP = Open Drip Proof. DD93

Specifications
Compliance Tab /content/product_tabs/p65warnings.html
ON SALE LIMITED TIME DISCOUNT
Voltage 575V
Horsepower 50 HP
RPM 1800
Phase Three Phase
Frame 326TS
Enclosure ODP
Hertz 60/50 Hz
Amperage 45 Amps
Bearings Ball Bearings
Service Factor 1.15
Insulation Class Class F
Mounting Rigid Base
!
