DHP0154 TECO-Westinghouse 15 HP 1800 RPM 254T 230/460V ODP Cast Iron 3-Phase Motor

DHP0154 TECO-Westinghouse 15 HP 1800 RPM 254T 230/460V ODP Cast Iron 3-Phase Motor

The DHP0154 is a TECO-Westinghouse general-purpose electric motor designed for industrial applications such as pumps, fans, and compressors. It replaces standard motors requiring a reliable 15 HP, 3-phase power source with inverter duty capabilities.

Key Specifications

• Horsepower: 15 HP
• RPM: 1800
• Voltage: 230/460V
• Amperage: 35.7/17.9 A
• Enclosure: Open Drip Proof (ODP)
• Frame / Diameter: NEMA 254T
• Shaft Dimensions: 4 x 1 5/8" Diameter, Keyed
• Rotation: Reversible
• Bearings: Ball Bearings

Product Features & Fitment

This motor features a rugged cast iron frame with a rigid base for stable mounting and long service life. It is designed with Class F insulation and is suitable for inverter use, supporting a speed range of 20:1 for variable torque and 10:1 for constant torque applications. The motor is NEMA Premium efficient and complies with UL, CSA, and CE standards. Thermal overload protection is not included.

Warranty

1 Year Manufacturer Warranty
